This manual introduces the basic knowledge of the D-Link DAP-2360 wireless AP, including function features, wireless settings, hardware interfaces, configuration methods and so on.
The DAP-2360 is a 802.11n wireless access point that supports PoE and offers four operational modes: Access Point, WDS with AP, WDS, and Wireless Client. It is designed for office, trade‑show and other environments where flexible, high‑speed Wi‑Fi connectivity is needed.
The manual covers product overview, hardware details, installation guidelines, web‑based configuration, advanced settings such as VLAN and QoS, security options, technical specifications, and warranty information.
| Wireless Standards | IEEE 802.11b / 802.11g / 802.11n |
|---|---|
| Data Rates (802.11b) | 1, 2, 5.5, 11 Mbps |
| Data Rates (802.11g) | 6‑54 Mbps (multiple steps) |
| Data Rates (802.11n) | Up to 300 Mbps (HT40) |
| Wireless Frequency Range | 2.4 GHz – 2.4835 GHz |
| Operating Voltage | 48 V DC ± 10 % (PoE) or 5 V / 2.5 A |
| Power Consumption | Max 8 W (5 V DC) / Max 9 W (PoE) |
| Antenna Gain | 5 dBi @ 2.4 GHz |
| Dimensions (L×W×H) | 188 mm × 166 mm × 37 mm |
| Operating Temperature | 0 °C to 40 °C |
It supports IEEE 802.11b, 802.11g, and 802.11n standards.
The device can be powered via 48 V PoE (IEEE 802.3af) or with the supplied 5 V/2.5 A power adapter.
In 802.11n mode the access point can achieve up to 300 Mbps.
The unit measures 188 mm × 166 mm × 37 mm (L × W × H).
