The document describes the M74HC174 high-speed CMOS hex D-type flip-flop with clear. It features high speed, low power dissipation, high noise immunity, symmetrical output impedance, balanced propagation delays, and a wide operating voltage range.
The M74HC174 is a high‑speed CMOS hex D‑type flip‑flop with clear, offered in DIP‑16, SOP, and TSSOP packages. It features a wide operating voltage range, low power dissipation and balanced propagation delays.
The datasheet provides absolute maximum ratings, recommended operating conditions, DC and AC electrical characteristics, mechanical dimensions and test circuit information for designers.
| Supply Voltage (absolute max) | -0.5 V to +7 V |
|---|---|
| Power Dissipation | 500 mW (typ at 65 °C) |
| Storage Temperature Range | -65 °C to +150 °C |
