CD4030B is an integrated circuit chip produced by Texas Instruments Incorporated.
This Texas Instruments datasheet describes the CD4030B quad 2‑input XOR gate. It lists the available package types, including 14‑lead hermetic dual‑in‑line ceramic, 14‑lead dual‑in‑line plastic, 14‑lead small‑outline, and 14‑lead thin‑shrink small‑outline packages, along with their mechanical dimensions and material information.
Additional sections provide packaging and tape‑and‑reel data, eco‑plan classifications (Pb‑Free RoHS and Green), moisture sensitivity level guidance, and maximum soldering temperature limits. The document also contains legal notices and warranty information from Texas Instruments.
| Package Type (example) | PDIP |
|---|---|
| Leads per package | 14‑lead |
| Maximum soldering temperature | 260 °C |
| Eco‑plan (RoHS status) | Pb‑Free (RoHS) |
| SOIC package dimensions (L×W×H) | 34.6 mm × 34.6 mm × 3.3 mm |
The CD4030B is supplied in 14‑lead hermetic dual‑in‑line ceramic, 14‑lead dual‑in‑line plastic, 14‑lead small‑outline, and 14‑lead thin‑shrink small‑outline packages.
The maximum soldering temperature is specified as 260 °C.
