Maxim DG304(A) CMOS Analog Switch Data Sheet

This is the datasheet for DG304(A)/DG305(A)/DG306(A)/DG307(A) CMOS Analog Switches

Brand: Maxim
Category: Other Electronics
Document type: Datasheet
Language: Chinese
Pages: 9
File format: PDF
File size: 1.1 MB
Published: 07 May, 2012
Updated: 30 September, 2023
Model: DG304
MD5 checksum: 5F15736F2EFC36D4DD354E786CD25D37
PDF: Maxim DG304(A) CMOS Analog Switch Data Sheet PDF

About this manual

The DG304(A)‑DG307(A) family are CMOS analog switches offered by Maxim Integrated Products. They are intended for use in a variety of signal routing applications where low on‑resistance and high isolation are required.

This data sheet provides ordering information, package drawings for PDIP and SOIC variants, and contact details for obtaining the latest specifications. Package outlines and dimensions are listed, and Maxim’s disclaimer and revision data are included at the end. This manual is written in Chinese.

What's inside

Ordering Information
Package Information
Package Outline
Document Control
Contact Information
