The DC1000 Series are microprocessor-based controllers designed with a high degree of functionality and reliability at a competitive price.
The DC1000 series digital controllers are microprocessor‑based devices that support temperature, humidity, pressure, flow and other process variables. They are offered in several DIN sizes (48×48, 48×96, 72×72, 96×96) and include dual displays, LED bar‑graph, and extensive alarm and communication options.
The manual details configuration levels, control algorithms (PID, ON/OFF, heat/cool, motor position), auto‑tuning, set‑point programming, and optional RS‑232/RS‑485 Modbus communication. Technical specifications, wiring, and warranty information are also included.
| Power supply voltage | 100‑240 V AC 50/60 Hz, 8 VA max; 15‑50 V DC, 10 VA max |
|---|---|
| Front face protection | IP65 |
| Communication speed | up to 38 400 bps |
| Relay rating | 3 A, 220 V AC resistive load |
The controllers can use RS‑232 or RS‑485 with optional Modbus RTU/ASCII protocols, up to 38 400 bps.
Two programs can be stored, each with up to eight segments.
The front face is rated IP65 for protection against dust and moisture.
