AD10048P3L-001 is a 100 watt portable embedded power supply that features active power factor correction, EN6100-3-2 compliance, CE Mark EMC and LVD, universal ac input, fully regulated output, overcurrent, overvoltage and thermal protection, constant voltage, high efficiency, high MTBF, IEC320 ac receptacle, 3 pin (type C6), built in EMI filter (CISPR 22 class B), AC Input fuse, complies with One Watt Input Energy Star / Blue Angel requirement.
The AD10048P3L-001 is an embedded power module designed for business‑critical continuity. It delivers 100 W total power with a single 48 Vdc output from a wide 90‑264 Vac input range and includes active power‑factor correction, high efficiency, and built‑in EMI filtering.
The unit meets multiple safety standards (UL 60950‑1, CSA‑C22.2, NEMKO EN/IEC60950‑1) and environmental requirements (EN61000 series). Physical dimensions are 1.47 in H × 2.56 in W × 6.14 in L, weight 1.11 lb, and it is covered by a 2‑year warranty.
| Total Power | 100 W |
|---|---|
| Input Voltage | 90‑264 Vac |
| Number of Outputs | Single |
| Output Voltage | 48 Vdc |
| Efficiency | 90 % typical |
| Operating Temperature | 0 °C to +45 °C |
| Storage Temperature | -40 °C to +70 °C |
| MTBF | >300,000 h at full load, 25 °C |
| Dimensions (H × W × L) | 1.47 in × 2.56 in × 6.14 in |
The unit operates from 90 Vac to 264 Vac.
It is certified to UL 60950‑1, CSA‑C22.2 no.60950‑1, and NEMKO EN/IEC60950‑1.
The module provides up to 100 W of total power.
