This catalog introduces the ITT Cannon 1.0/2.3 RF connector series, which is offered in both 50 Ω and 75 Ω versions for telecom and high‑speed digital equipment. The range includes straight and right‑angle plugs, jacks, surface‑mount versions, baluns, U‑links, and various adaptors, all featuring a push‑pull coupling mechanism.
Detailed electrical and mechanical specifications, part numbers, tooling information, assembly instructions, and product safety guidelines are provided. The document also lists worldwide Cannon facilities and contact information.
| Impedance | 50 Ω / 75 Ω nominal |
|---|---|
| Frequency Range | 0 – 2 GHz |
| Voltage Rating | 250 Vrms (sea level) |
| Insulation Resistance | 1000 MΩ minimum |
| Inner Contact Resistance (50 Ω) | 4 mΩ maximum |
| Inner Contact Resistance (75 Ω) | 6 mΩ typical maximum |
| Outer Contact Resistance | 2.5 mΩ maximum |
| Insertion Force (minimum) | 0.2 N (0.04 lb) |
| Withdrawal Force – Inner Female | 0.7 N (0.15 lb) minimum |
| Withdrawal Force – Outer Male | 10 N (2.24 lb) maximum |
| Materials – Body and Nuts | Brass |
| Contact Surface Plating | Gold over Nickel |
| Operating Temperature Range | -40 °C to 85 °C |
| Mating Cycles | 500 minimum |
| Standards | CECC 22230, DIN 47297 |
The connectors are offered in both 50 Ω and 75 Ω versions.
They are rated for 250 Vrms at sea level.
They meet CECC 22230 and DIN 47297 specifications.
The connectors are specified for -40 °C to 85 °C.
