TL-SF1008P is an 8 10/100M ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs).
The TL‑SF1008P is an 8‑port 10/100 Mbps unmanaged desktop switch that includes four Power over Ethernet (PoE) ports. It automatically detects IEEE 802.3af‑compliant powered devices and delivers data and power over a single cable, simplifying installations for access points, IP cameras, and IP phones.
Key features include a priority function that disables the lowest‑priority port when power is overloaded, auto‑negotiation on all RJ45 ports, a 1 K entry MAC address table with auto‑learning and aging, and LED indicators for power, link, activity, and speed. The device operates from an external 48 VDC adapter and meets CE and FCC certifications.
| Number of RJ45 ports | 8 (10/100 Mbps auto‑negotiation) |
|---|---|
| PoE ports | 4 (port‑1 to port‑4) |
| Maximum PoE power per port | 15.4 W |
| Maximum total PoE power | 53 W |
| MAC address table size | 1 K entries |
| Power consumption (no PD) | 5.8 W |
| Power consumption (with 53 W PD) | 58 W |
| Dimensions (L×W×H) | 6.7 × 3.9 × 1.1 in (17.1 × 9.8 × 2.7 mm) |
| Operating temperature | 0 °C ~ 40 °C |
| Storage temperature | -40 °C ~ 70 °C |
It has four PoE ports, labeled port‑1 to port‑4.
Each PoE port can supply up to 15.4 W of power.
The switch measures 6.7 × 3.9 × 1.1 in (17.1 × 9.8 × 2.7 mm).
