This manual covers the features and functions of the SM320F2810-EP, SM320F2811-EP, SM320F2812-EP SM320C2810-EP, SM320C2811-EP, SM320C2812-EP digital signal processors.
This data manual covers the SM320F2810‑EP, SM320F2811‑EP, SM320F2812‑EP, SM320C2810‑EP, SM320C2811‑EP, and SM320C2812‑EP digital signal processors. It includes a description of each device, pin and terminal assignments for the GHH, PGF, and PBK packages, signal descriptions, functional block diagrams, memory maps, and peripheral overviews such as ADC, eCAN, McBSP, SCI, and SPI modules.
The document also provides electrical specifications (absolute maximum ratings, recommended operating conditions, current consumption) and mechanical data, including package dimensions and options. An addendum lists package options and ordering information for the ACTIVE BGA (GHH) and LQFP (PGF) variants.
| Package (GHH) | 179‑ball BGA (MicroStar) |
|---|---|
| Package (PGF) | 176‑pin LQFP |
| Literature Number | SGUS051A |
| Original Publication Date | March 2004 (revised October 2004) |
The literature number is SGUS051A.
It was first published in March 2004 and revised in October 2004.
