This document is a guide for maintenance operations preparations before using the OWNER'S MANUAL DATA PROJECTOR TDP-S35 (SVGA) TDP-SC35 (SVGA / With Document Camera), describing the features and characteristics of the products.
The manual begins with safety precautions, warning users not to expose the projector to rain or moisture and to avoid opening the cabinet, as the unit contains dangerous voltage. It also details power‑supply cord selection, remote‑control battery requirements, and proper handling of accessories.
Subsequent sections describe basic operation, menu navigation, document‑camera usage, lamp replacement, and troubleshooting. The specifications chapter lists supported video formats, signal frequencies and pin assignments for RGB and component inputs.
| Supported video formats | NTSC, PAL, SECAM, PAL‑M, PAL‑N, PAL‑60, NTSC4.43 |
|---|---|
| Supported resolutions | 480i, 480p, 576i, 576p, 720p, 1080i |
| Remote control battery type | AA size batteries |
Do not expose the appliance to rain or moisture, as dangerous high voltages are present inside the enclosure.
The remote control requires AA size batteries.
Never remove the cabinet cover; opening it may expose the user to dangerous voltage and should be done only by qualified service personnel.
RGB input uses 0.7 V (p‑p) signals with standard frequencies such as 15.73 kHz for NTSC and 15.63 kHz for PAL.
