This is a technical literature for TFT-LCD module, LQ104S1LG61
The Sharp LD-19164A is a 26‑inch (10.4") color active‑matrix TFT‑LCD module with an amorphous silicon TFT. It integrates a TFT‑LCD panel, driver ICs, control circuitry, power supply, and a backlight unit, offering 800×600 resolution and 262,144 colors via an LVDS interface.
The module delivers a high brightness of 420 cd/m² and a contrast ratio of 500:1, with a low‑reflection, high‑color‑saturation panel suitable for multimedia applications. It requires +3.3 V and +5.0 V DC supplies for panel driving and does not include a built‑in backlight inverter.
| Display size | 26 (10.4") diagonal |
|---|---|
| Active area | 211.2 mm × 158.4 mm |
| Resolution | 800 × 600 pixels |
| Number of colors | 262,144 colors |
| Pixel pitch | 0.264 mm × 0.264 mm |
| Unit dimensions | 246.5 mm × 179.4 mm × 15.5 mm (W×H×D) |
| Mass | 620 g max |
| Brightness | 420 cd/m² |
| Contrast ratio | 500:1 |
| Panel supply voltage | +3.3 V / +5.0 V DC |
| Operating temperature | -30 °C to +80 °C |
It has an 800 × 600 pixel format.
The panel requires +3.3 V and +5.0 V DC power supplies.
The module can operate from –30 °C to +80 °C.
The display provides 420 cd/m² brightness.
