This document is a service manual that mainly introduces the specifications, names of parts, operation manual, adjustments, performance check and firmware upgrade, disassembly and reassembly, diagrams, etc. of the TM200 digital mobile phone produced by Sharp Corporation.
This service manual covers the Sharp TM200 digital mobile phone, providing detailed specifications, safety precautions, disassembly/reassembly procedures, and wiring diagrams. It also describes how to use the Sharp Program Support Tool (SPST) for data backup, firmware upgrades, and performance checks.
The document includes part lists, adjustment steps after component replacement, and connector pinouts, helping technicians service the handset safely and efficiently.
| Camera resolution | 2 Megapixel |
|---|---|
| Main display size | 2.2 inch |
| Battery capacity | 840 mAh |
| Weight | 120 g |
| Supported frequency bands | 900/1800/1900 MHz |
Use the Sharp Program Support Tool (SPST) to back up the handset’s data before any repair work.
Wear static‑electricity prevention bands while servicing the handset.
