Panasonic BT-LH1700WP LCD Video Monitor Operating Instructions

This manual describes the operation of the BT-P S0805M1095-H LCD Video Monitor.

Brand: Panasonic
Category: Monitoring Equipment
Document type: User Manual
Language: English
Pages: 30
File format: PDF
File size: 829 KB
Published: 03 May, 2012
Updated: 30 September, 2023
MD5 checksum: 6032206D07D9F7B24733644FA189D829
PDF: Panasonic BT-LH1700WP LCD Video Monitor Operating Instructions PDF

About this manual

This manual covers safety precautions, grounding requirements, and environmental limits for the BT‑LH1700WP LCD video monitor. It explains how to install the unit, connect power and signal cables, and mount the monitor in a rack or on a stand.

The document also describes the front‑panel controls, remote functions, input connectors (SDI, VIDEO, Y/C, YPsPr/RGB), on‑screen menu navigation, and detailed technical specifications such as voltage range, screen size, and supported broadcast formats.

What's inside

Safety Instructions
Precautions for Use
Dimensions
Controls and Their Functions
Front Panel
Rear Panel
Power Supply
On‑Screen Menu
Specifications
Maintenance

Specifications

Operating voltage range	100 – 240 V AC
Screen size	17.1‑inch LCD panel
Video input connectors	SDI (HD/SD), VIDEO, Y/C, YPsPr/RGB
Supported broadcast standards	NTSC and PAL

Frequently asked questions

What voltage range can the BT‑LH1700WP operate on?

It can be operated at a voltage in the range of 100 – 240 V AC.

Which video input connectors are available on the monitor?

The monitor provides SDI (HD/SD compatible), VIDEO, Y/C, and YPsPr/RGB input jacks.

Does the monitor support NTSC and PAL broadcast systems?

Yes, it supports both NTSC and PAL TV broadcast systems.
