TUSB3410 and TUSB3410I are USB to Serial Port Controllers from Cypress Semiconductor that supports USB 2.0 and UART standards.
The TUSB3410 bridges a USB port to an enhanced UART serial port, integrating a 8052 microcontroller with 16 KB RAM, 10 KB ROM, and a built‑in two‑channel DMA controller. It supports USB 2.0 full‑speed (12 Mbps), multiple power modes, and a range of UART features including hardware flow control, RS‑485 transceiver control, and IrDA mode.
The manual includes a complete register map, memory map, electrical characteristics, and application notes such as crystal selection and wake‑up timing. It also details the bootcode programming flow, GPIO configuration, and I²C port usage for external memory access.
| Supply voltage (VCC) | 3.3 V (typical) |
|---|---|
| Input voltage range | -0.5 V to 3.6 V |
| Operating temperature (commercial) | 0 °C to 70 °C |
| Operating temperature (industrial) | -40 °C to 85 °C |
| UART baud‑rate range | 50 bps to 921.6 kbps |
| USB data rate | 12 Mbps (full speed) |
| GPIO terminals | Four |
The device is rated for an industrial temperature range of –40 °C to 85 °C.
The controller provides four GPIO terminals on the 8052 port 3.
It supports the USB 2.0 full‑speed data rate of 12 Mbps.
