The ADF4360-8 is an integrated integer-N synthesizer and voltage-controlled oscillator (VCO) with an output frequency range of 65 MHz to 400 MHz. It features programmable output power level and digital lock detect function.
The ADF4360-8 is an integrated integer‑N synthesizer and voltage‑controlled oscillator (VCO) whose output frequency can be set between 65 MHz and 400 MHz using external inductors. It operates from a 3.0 V to 3.6 V supply, supports 1.8 V logic, and is controlled via a simple 3‑wire serial interface.
The document includes functional block diagrams, pin configurations, absolute maximum ratings, timing characteristics, typical performance data, output‑matching recommendations, package dimensions, and ordering information. It also lists typical applications such as system clock generation, test equipment, wireless LANs, and CATV equipment.
| Output frequency range | 65 MHz to 400 MHz |
|---|---|
| Supply voltage (analog and digital) | 3.0 V to 3.6 V |
| Logic compatibility | 1.8 V |
| Phase detector maximum frequency | 8 MHz |
| Typical lock time | 400 µs |
| Operating temperature range | -40 °C to +85 °C |
| Maximum junction temperature | 150 °C |
| Transistor count | 12 543 CMOS, 700 Bipolar |
The device can generate frequencies from 65 MHz up to 400 MHz.
It operates from a 3.0 V to 3.6 V analog and digital power supply.
Typical lock time is 400 µs.
It is rated for operation from –40 °C to +85 °C.
