The ADF4360-5 is an integrated integer-N synthesizer and voltage-controlled oscillator (VCO) designed for a center frequency of 1300 MHz. It also offers a divide-by-2 option for an RF output of between 600 MHz and 700 MHz. All on-chip registers are controlled through a simple 3-wire interface.
The ADF4360-5 is a fully integrated integer‑N synthesizer and voltage‑controlled oscillator designed for a center frequency of 1300 MHz, with an optional divide‑by‑2 output yielding 600‑700 MHz. It operates from a 3.0 V to 3.6 V supply, supports 1.8 V logic, and is controlled via a simple 3‑wire serial interface (CLK, DATA, LE).
The document provides detailed specifications, absolute maximum ratings, pin configuration, typical performance characteristics, ordering information, and application examples such as wireless handsets, test equipment, and LANs.
| Output frequency range | 1200 MHz to 1400 MHz |
|---|---|
| Power supply voltage | 3.0 V to 3.6 V |
| Logic compatibility | 1.8 V logic |
| Output power level | -13.5 to -4.5 dBm (typ) |
| Phase‑noise (100 kHz offset) | -110 dBc/Hz typ |
It covers 1200 MHz to 1400 MHz.
The analog and digital supplies range from 3.0 V to 3.6 V.
Control is via a 3‑wire serial interface (CLK, DATA, LE).
The device operates from –40 °C to +85 °C.
