ADF4116/ADF4117/ADF4118 are RF PLL frequency synthesizers with a frequency range of 550 MHz to 3.0 GHz, a power supply range of 2.7 V to 5.5 V, and extended tuning voltage capability in 3 V systems. They can be used to implement local oscillators (LO) in the upconversion and downconversion sections of wireless receivers and transmitters. These frequency synthesizers feature a low noise digital phase frequency detector (PFD), a precision charge pump, a programmable prescaler, digital lock detect, power-down mode, and fastlock mode.
The ADF4116/ADF4117/ADF4118 family are RF PLL frequency synthesizers designed for use as local oscillators in wireless transmitters and receivers. They integrate a low‑noise digital phase‑frequency detector, charge pump, programmable reference divider, A and B counters and a dual‑modulus prescaler, all controlled via a 3‑wire serial interface.
The document provides detailed specifications, pin configurations, timing characteristics, absolute maximum ratings and typical performance graphs, enabling designers to implement the devices in GSM, CDMA, WCDMA, LAN and test equipment applications.
| RF Input Frequency (ADF4116) | 80 to 550 MHz |
|---|---|
| Power‑down Current (ADF4117) | 5.5 mA max, 4.5 mA typical |
| Operating Temperature (Y version) | ‑40 °C to +125 °C |
The Y‑version devices are rated from ‑40 °C to +125 °C.
