ADF4360-0 is an integrated digital frequency synthesizer and voltage-controlled oscillator (VCO) from Analog Devices, with a frequency range of 2400 MHz to 2725 MHz and an output power of 3.0 V to 3.6 V, compatible with 1.8 V logic.
The ADF4360-0 is a fully integrated integer‑N synthesizer and voltage‑controlled oscillator (VCO) designed for a center frequency of 2600 MHz, with an optional divide‑by‑2 output for 1200‑1360 MHz RF. Control of all on‑chip registers is performed via a simple 3‑wire serial interface, and the device operates from a 3.0 V to 3.6 V supply.
The document lists detailed electrical specifications, absolute maximum ratings, pin configuration, timing characteristics, typical performance data, and recommended PCB design guidelines. It also outlines typical applications such as wireless handsets, test equipment, WLAN, CATV, and other RF systems.
| Output frequency range | 2400 MHz to 2725 MHz |
|---|---|
| Power supply voltage | 3.0 V to 3.6 V |
| Logic compatibility voltage | 1.8 V |
| Interface type | 3‑wire serial interface |
| Phase detector maximum frequency | 8 MHz |
| VCO output power | -13 dBm to -6.5 dBm |
| Operating temperature range | -40 °C to +85 °C |
| Input high voltage (logic) | 15 V min |
| Input low voltage (logic) | 0.6 V max |
The device can generate frequencies from 2400 MHz up to 2725 MHz.
It operates from a 3.0 V to 3.6 V power supply.
All registers are accessed via a simple 3‑wire serial interface.
The device is rated for -40 °C to +85 °C.
