The EASY719-AB-RCX is a relay module from Easyson. It has 12 digital inputs (4 inputs can be used as analog inputs), 6 relay outputs, screw terminals, a timer, and can be expanded using Easyson expansion units.
This handbook details the technical data of the Moeller EASY719-AB-RCX relay module, including its power supply requirements, relay output count, and environmental ratings. It also lists mechanical dimensions, mounting options, and protection classes.
Additional sections cover electromagnetic compatibility, real‑time clock backup, input/output characteristics, and safety isolation specifications, making it a comprehensive reference for engineers and installers.
| Relay outputs | 6 |
|---|---|
| Power supply | 24 V AC |
| Rated operational voltage | 24 V AC |
| Dimensions (W x H x D) | 107.5 mm × 90 mm × 58 mm |
The module operates on a 24 V AC power supply.
It provides six relay outputs.
The module measures 107.5 mm × 90 mm × 58 mm (W × H × D).
