The EASY512-AC-RCX is a programmable controller from Schaeffler Electric with 8 digital inputs, 6 relay outputs and support for 115/230V AC power supply. The product also features backup real-time clock, working time and more.
The EASY512-AC-RCX is a relay output module with eight digital inputs and six relay outputs, designed for use with 115/230 V AC power supplies. It includes screw terminals, a real‑time clock backup, and optional LCD display.
The module complies with IEC/EN standards for climatic conditions, electromagnetic compatibility, and mechanical shock. It is mounted on a top‑hat rail or screw‑fixed, measures 71.5 × 90 × 58 mm, weighs about 0.2 kg, and carries an IP20 protection rating. Operating temperature ranges from –40 °C to +70 °C with 5‑95 % non‑condensing humidity.
| Relay outputs | 6 |
|---|---|
| Digital inputs | 8 |
| Power supply voltage | 115/230 V AC |
| Operating voltage range | 100/110/115/120/230/240 AC |
| Dimensions (W × H × D) | 71.5 × 90 × 58 mm |
| Maximum rated operational voltage (AC) | 300 V |
| Maximum rated operational voltage (DC) | 300 V |
The module provides six relay outputs.
It operates from 115 V to 230 V AC (or VDC 115/230 V AC).
