The ADG1204 is a low voltage drop, low capacitance, ±15 V/+12 V, 4:1 iCMOS multiplexer, suitable for applications such as automatic test equipment, data acquisition systems, battery-powered systems, sample-and-hold systems, audio signal routing, video signal routing and communication systems.
The ADG1204 is a CMOS analog multiplexer offering four single‑ended channels with ultra‑low off‑capacitance (1.5 pF) and charge injection (<1 pC). It operates from a dual ±15 V supply or a single 12 V supply, consumes less than 0.03 pW typical power, and is available in 14‑lead TSSOP and 12‑lead LFCSP packages.
The datasheet provides detailed specifications, absolute maximum ratings, pin configurations, truth table, outline dimensions, and ordering information for the ADG1204. It also lists typical applications such as automatic test equipment, data acquisition, battery‑powered systems, and video signal routing.
| Off‑Capacitance | 1.5 pF |
|---|---|
| Charge Injection | <1 pC |
| On Resistance (Ron) | 120 Ω typical |
| Supply Voltage Range (dual) | ±15 V (33 V total) |
| Typical Power Consumption | <0.03 pW |
The typical on resistance is 120 Ω.
It can operate from a dual ±15 V supply (33 V total) or a single 12 V supply.
The off‑capacitance is 1.5 pF.
Typical power consumption is less than 0.03 pW.
