This is a summary of the ASRock 4Core1600-DVI user manual
This manual introduces the ASRock 4Core1600-DVI motherboard, its layout, and the steps required to install the CPU, memory, storage, and other components. It also covers the BIOS setup utility, hardware health monitoring, and software support options.
Additional sections detail the rear I/O connectors, supported operating systems, and troubleshooting tips, helping users configure the system for optimal performance and stability.
| Form Factor | Micro ATX (9.6 in x 9.6 in) |
|---|---|
| CPU Socket | LGA 775 |
| Supported CPUs | Intel Core2 Extreme/Quad/Duo, Pentium Dual Core, Celeron |
| Chipset | Northbridge: Intel G31, Southbridge: Intel ICH7 |
| Expansion Slots | 1 x PCI‑Express x16, 1 x PCI‑Express x1, 2 x PCI |
| Audio | 5.1‑channel Windows Vista Premium Level HD Audio (ALC662) |
| LAN | Gigabit LAN (Realtek RTL8111B/RTL8111C) |
It uses an LGA 775 socket for Intel® Core™ 2 and compatible processors.
It provides dual VGA outputs: a D‑Sub port and a DVI‑D port via the DVI Graphics‑SI card.
