The 3235C2 accelerometer features high-temperature operation, high charge sensitivity, extreme stability over temperature and balanced differential output.
This document provides the outline drawing and essential specifications for the Dytran 3235C2 single‑axis differential charge‑mode accelerometer. It includes physical dimensions, connector details, and a list of supplied accessories such as the mounting screw and calibration certificate.
Key performance data are listed, covering sensitivity, operating temperature range, frequency response, resonance frequency, insulation resistance, shock and vibration limits, as well as magnetic and base‑strain sensitivities. Environmental ratings and material information are also provided to aid installation and integration.
| Model Number | 3235C2 |
|---|---|
| Operating Temperature | -60 to 550 °F (-51 to 287 °C) |
| Frequency Range | ±10,000 Hz |
| Resonance Frequency | 35 kHz |
| Insulation Resistance (75 °F) | 250 GΩ |
| Capacitance (pin‑to‑pin) | 3200 pF |
| Shock Rating | 2000 g pk |
| Vibration Rating | 1000 g pk |
| Magnetic Sensitivity (100 Gauss) | 0.000008 g/Gauss |
| Weight | 1.9 oz (55 g) |
The 3235C2 operates from –60 °F to 550 °F (–51 °C to 287 °C).
It uses a 2‑Pin Glass‑To‑Metal Seal connector that mates with a Glenair G345‑1 plug.
The resonance frequency is 35 kHz.
