The STPS41H100CG/CT/CR is a 3A low drop power Schottky rectifier, suitable for Switch Mode Power Supply and high frequency DC to DC converters. Packaged in D2PAK, I2PAK and TO-220AB, this device is intended for use in high frequency inverters.
The STPS41H100 series are low‑drop Schottky rectifiers designed for switch‑mode power supplies and high‑frequency DC‑DC converters. They are offered in DPAK, I7PAK, and TO‑220AB packages (CG, CT, CR) and feature negligible switching losses, low leakage, and avalanche capability.
Key characteristics include a repetitive peak reverse voltage of 100 V, an average forward current rating of up to 20 A, a maximum junction temperature of 175 °C, and low thermal resistance. Detailed mechanical dimensions for each package are provided, along with thermal impedance curves and ordering information.
| Repetitive peak reverse voltage (VrRRM) | 100 V |
|---|---|
| Maximum junction temperature (Tj max) | 175 °C |
| Maximum forward voltage (Vr max) | 0.67 V |
| Junction‑to‑case thermal resistance (Rint‑c) | 1.5 °C/W |
The device can withstand a repetitive peak reverse voltage of 100 V.
At 20 A and 25 °C the forward voltage drop is typically 0.80 V.
The device is rated for a maximum junction temperature of 175 °C.
