MC74HC04A is a high-performance hex inverter with six three-stage inverters. It can drive 10 LSTTL loads and directly interface with CMOS, NMOS, and TTL. It operates in a voltage range of 2.0 to 6.0V and has low input current and high noise immunity characteristics.
The MC74HC04A is a high‑performance silicon‑gate CMOS hex inverter compatible with standard CMOS, NMOS, and TTL logic families. It contains six three‑stage inverters and is offered in Pb‑free PDIP‑14, SOIC‑14, and TSSOP‑14 packages.
Key specifications include a 2.0 V to 6.0 V operating voltage range, 10 LSTTL load drive capability, 1 pA low input current, and up to 750 mW power dissipation in a plastic DIP package. Ordering information and detailed package dimensions are provided for each package type.
| Output Drive Capability | 10 LSTTL Loads |
|---|---|
| Operating Voltage Range | 2.0 to 6.0 V |
| Low Input Current | 1 pA |
| Power Dissipation (Plastic DIP) | 750 mW |
| Maximum Supply Voltage | -0.5 to +7.0 V |
The device operates from 2.0 V to 6.0 V.
Each output can drive up to 10 LSTTL loads.
The low input current is specified as 1 pA.
