This document introduces the L78xx series of three-terminal positive voltage regulators, including models, features, packages, and maximum ratings.
The L78xx family of three‑terminal positive voltage regulators is offered in TO‑220, TO‑220FP, TO‑3, D‑PAK and D‑PAK packages with fixed output voltages ranging from 5 V to 24 V. Each device includes internal current limiting, thermal shutdown and safe‑area protection, allowing reliable operation up to 1.5 A when adequate heat sinking is provided.
The document lists absolute maximum ratings, thermal data, electrical characteristics, typical performance graphs, mechanical dimensions and ordering codes. Revision history and legal notices are also included.
| Maximum output current | 1.5 A |
|---|---|
| Available fixed output voltages | 5 V, 6 V, 8 V, 8.5 V, 9 V, 12 V, 15 V, 18 V, 24 V |
| Storage temperature range | -65 °C to 150 °C |
| Operating junction temperature range (L7800C) | 0 °C to 150 °C |
The regulators can deliver up to 1.5 A of output current.
They can be stored from –65 °C up to 150 °C.
