The AD-o81CL is a progressive‑scan monochrome camera featuring two CCD sensors. It delivers an effective image size of 4024 × 768 pixels with a pixel pitch of 4.65 µm, supporting up to 60 fps in full‑frame mode and various partial‑readout modes for higher frame rates.
The camera outputs digital video via Camera Link (8‑bit/10‑bit, 2‑channel) and offers analog video, programmable shutter, and gain control. It operates from a 12 V DC supply, tolerates temperatures from –5 °C to +45 °C, and complies with CE, FCC Class B, and RoHS/WEEE standards. This manual is written in Japanese.
| Effective pixel count | 4024 × 768 |
|---|---|
| Pixel size | 4.65 µm × 4.65 µm |
| Dynamic range | 118 dB |
| Signal‑to‑noise ratio | ≥54 dB |
| Digital video output | Camera Link 8‑bit/10‑bit, 2 channels |
| Operating temperature range | -5 °C to +45 °C |
| Power supply | DC 12 V |
| Dimensions (W × H × D) | 55 mm × 55 mm × 80 mm |
| Weight | 400 g |
It provides an effective pixel count of 4024 × 768.
The camera outputs digital video via a Camera Link interface with 8‑bit/10‑bit, 2‑channel mode.
It operates from –5 °C up to +45 °C.
The camera offers a high dynamic range of up to 118 dB.
