STPS41L60CG/CT/CR is a 3A power Schottky rectifier suitable for Switch Mode Power Supply and high frequency DC to DC converters. Packaged in D2PAK, I2PAK and TO-220AB this device is intended for use in low voltage, high frequency inverters, free-wheeling and polarity protection applications.
The STPS41L60 series are dual‑center‑tab Schottky rectifiers designed for switch‑mode power supplies, high‑frequency DC‑DC converters, and free‑wheeling applications. They are offered in DPAK, TO‑220AB and other packages and are suitable for low‑voltage, high‑frequency inverter and polarity‑protection circuits.
The document lists key electrical ratings such as a 60 V repetitive peak reverse voltage, 30 A RMS forward current and a typical forward voltage drop of 0.60 V at 20 A (25 °C). Thermal characteristics, including a junction‑to‑case resistance of 1.5 °C/W and storage temperature range from –65 °C to +175 °C, are provided together with detailed mechanical dimensions for each package.
| Repetitive peak reverse voltage | 60 V |
|---|---|
| Forward voltage drop at 20 A, 25 °C | 0.60 V |
| Maximum operating junction temperature | 150 °C |
| Storage temperature range | -65 to +175 °C |
The device is rated for a repetitive peak reverse voltage of 60 V.
The forward voltage drop is about 0.60 V under those conditions.
