STPS3L60/Q/U is a Philips power Schottky rectifier designed for use in switch mode power supplies and high frequency DC to DC converters. It features negligible switching losses, low thermal resistance and avalanche capability. The diode is available in DO-201AD, DO-15 and SMB packages and is suitable for use in low voltage, high frequency inverters and small battery chargers. It can also be used in space constrained applications, such as telecom battery chargers.
The STPS3L60 series are axial and surface‑mount Power Schottky rectifiers designed for switch‑mode power supplies and high‑frequency DC‑DC converters. They are offered in DO‑201AD, DO‑15 and SMB (JEDEC DO‑214AA) packages and feature negligible switching losses, low thermal resistance and avalanche capability.
The document lists absolute ratings, static electrical characteristics, thermal resistances, and detailed mechanical dimensions for each package. It also includes typical curves for forward current versus ambient temperature, avalanche power derating, and thermal impedance, as well as ordering information for various package options.
| Average forward current (IF(av)) | 3 A |
|---|---|
| Repetitive peak reverse voltage (VrrM) | 60 V |
| Maximum junction temperature (Tj) | 150 °C |
| Maximum forward voltage (Ve max) | 0.61 V |
| Forward voltage drop at 25 °C, 3 A | 0.62 V |
| Package dimension A (DO‑15) min | 6.05 mm |
| Package dimension B (DO‑15) max | 3.53 mm |
The device can withstand a repetitive peak reverse voltage of 60 V.
It is available in DO‑201AD, DO‑15 and SMB (JEDEC DO‑214AA) packages.
Approximately 0.62 V.
