The MicroTouch ClearTek II touch system offers optimized optics, facilitates display integration, and is more environmentally friendly. It provides high endurance solutions for touch applications where exceptional performance, vibrant optics, and environmental robustness are critical, 24/7.
The MicroTouch ClearTek II capacitive touch system from 3M offers high optical transmission, a durable anti‑glare top coat, and robust performance even in contaminated environments. Designed with a re‑engineered 3M‑patented Profile, it integrates easily with displays ranging from 6.4" to 32" diagonal.
Key specifications include 91.5% (±1.5%) light transmission, 3 ms minimum contact time, and operation from –15 °C to 70 °C. The system is built to resist scratches (Mohs 7+), chemicals, liquids, and high humidity, making it suitable for 24/7 industrial applications.
| Light Transmission | 91.5% (±1.5%) |
|---|---|
| Glass Thickness | 3.18 mm (±0.25 mm) typical |
| Display Size Supported | 6.4" to 32" diagonal |
| Minimum Contact Time | 3 ms for finger input |
| Resolution | 1024 × 1024 default, up to 16K × 16K |
| Scratch Hardness | Mohs 7 or higher |
| Operating Temperature | -15 °C to 70 °C |
| Humidity | Up to 90% RH non‑condensing |
It provides 91.5% light transmission with a tolerance of ±1.5%.
The typical glass thickness is 3.18 mm with a tolerance of ±0.25 mm.
It operates from –15 °C up to 70 °C.
