AP358 is a low power dual operational amplifier with features including internal frequency compensation, large DC voltage gain, very low supply current drain, wide bandwidth, etc. It is suitable for transducer amplifiers, dc gain blocks, and other common op amp circuits.
The AP358 series from Diodes Incorporated consists of two internally frequency‑compensated operational amplifiers designed for single‑supply operation over a wide voltage range. It offers low supply current drain, large voltage gain, and input/output ranges that include ground, making it suitable for battery‑powered and transducer applications.
The datasheet provides full electrical characteristics, absolute maximum ratings, pin assignments, typical application circuits, and package dimensions for both SOP‑8L and PDIP‑8L versions. Ordering information and RoHS compliance details are also included.
| Supply Voltage Range | 3 V – 32 V (single) or +1.5 V – 16 V (dual) |
|---|---|
| Power Dissipation | 600 mW |
| Maximum Output Short‑Circuit Current | ≈ 40 mA |
The AP358 operates from a single supply of 3 V to 32 V, or from dual supplies of +1.5 V to +16 V.
The device can tolerate a short‑circuit current of roughly 40 mA.
