EDICusb is a flexible vehicle interface for automotive electronic products, supporting CAN, K-line, LIN bus interfaces and various Softing tools such as DTS, EDIABAS and VAS 5163.
The EDICusb provides a flexible vehicle interface for ECU communication, offering Plug&Play USB connectivity and support for multiple bus systems such as CAN, LIN and ISO 9141‑2. It can be used in stationary or mobile setups and includes optional Bluetooth for wireless testing.
Technical specifications include a compact 150 × 80 × 30 mm format, 300 g weight, 8‑32 V power supply from the vehicle, and a 16‑bit XC161CJ microcontroller. The device features two independent CAN channels, LIN master/slave capability, and a range of optional software and hardware extensions.
| Format | Approx. 150 x 80 x 30 mm |
|---|---|
| Weight | Approx. 300 g |
| Power supply | 8…32 V via vehicle diagnostic connector |
| Current consumption | Approx. 400 mA at 12 V |
| Microcontroller | 16‑bit XC161CJ, 40 MHz |
| USB interface | USB 2.0 Full Speed, 12 Mbit/s |
| Optional Bluetooth | Bluetooth V1.1 Class 2, range approx. 10 m |
| Vehicle interface | D‑Sub 25‑pin, galvanically isolated |
| CAN channels | 2 channels, high‑speed 1 Mbit/s, low‑speed 125 kbit/s |
| LIN support | Master or slave node |
| Temperature range | Operation 0 … +50 °C, Storage -25 … +70 °C |
| Noise emission compliance | EN 55022, EN 55011 Class A, EN 61000‑6‑4 |
| Interference immunity | EN 61000‑6‑2 |
The device operates from 8 V to 32 V supplied via the vehicle diagnostic connector.
Yes, an optional Bluetooth V1.1 Class 2 module with about 10 m range can be added on request.
