EDICblue is a wireless vehicle interface that is perfect for use in all areas of ECU communication. It is an efficient, easy-to-use and reasonably-priced interface to the vehicle electronics.
EDICblue provides a compact Bluetooth interface for vehicle electronics, enabling wireless connection between a vehicle and test systems in test‑drive, manufacturing, and service environments. It integrates a SAE‑J1962 diagnostic connector, allowing direct attachment to the vehicle and supporting parallel communication with multiple ECUs.
The device features a 16‑bit microcontroller, Bluetooth® V1.1/V2.0 Class 2 (≈10 m range), USB 2.0 full‑speed, and a CAN high‑speed channel (ISO 11898, CAN 2.0B) with optional low‑speed transceiver. Technical specifications include dimensions of 114 × 48 × 25 mm, weight ~100 g, power supply 8‑18 V via the diagnostic connector, and a current consumption of ~200 mA at 12 V.
| Dimensions | 114 x 48 x 25 mm |
|---|---|
| Weight | approx. 100 g |
| Power supply | 8‑18 V via vehicle diagnostic connector |
| Current consumption | Approx. 200 mA at 12 V |
| Microcontroller | 16‑bit XC161CJ, 40 MHz |
| Bluetooth version | V1.1 / V2.0, Class 2 (≈10 m range) |
| USB interface | USB 2.0 Full Speed, 12 Mbit/s, mini‑USB B |
| CAN channel | 1 high‑speed channel (ISO 11898, CAN 2.0B) with optional low‑speed transceiver |
| Operating temperature | 0 °C … +50 °C (operation), -20 °C … +85 °C (storage) |
| Digital input | Ignition signal evaluation |
| Power‑save mode | Automatic power‑off after settable time |
EDICblue supports CAN high‑speed (ISO 11898, CAN 2.0B) and, depending on the software package, ISO 9141‑2, UDS, KWP 2000, TP 2.0 and various OEM‑specific protocols.
It is powered from the vehicle diagnostic connector with a supply voltage of 8 V to 18 V and draws about 200 mA at 12 V.
EDICblue includes an integrated Bluetooth® V1.1/V2.0 Class 2 radio with an approximate range of 10 m.
The unit measures approximately 114 × 48 × 25 mm and weighs about 100 g.
