AMD Socket 393 CPU VIA K8T890 Chipsets user manual

This document is a user manual for AMD Socket 939 processors and VIA K8T890 chipsets, providing a list of common debug card codes and troubleshooting methods.

Brand: AMD
Category: Cpu
Document type: User Manual
Language: Chinese
Pages: 60
File format: PDF
File size: 10.8 MB
Published: 06 April, 2012
Updated: 29 September, 2023
Model: K8T890
MD5 checksum: 7EEBAA1B2EC8F20AD92C0945D491D3E3
PDF: AMD Socket 393 CPU VIA K8T890 Chipsets user manual PDF

About this manual

This manual provides detailed information for an ASUS motherboard built for AMD Socket 939 processors and the VIA K8T890 chipset. It includes packaging contents, a system block diagram, full motherboard specifications, step‑by‑step installation instructions, BIOS configuration, and RAID setup procedures.

The document also lists hardware interfaces such as PCI/PCI‑E slots, USB ports, IDE/SATA connectors, audio and networking components, and explains power‑saving features like Cool’n’Quiet and PowerBIOS overclocking options. This manual is written in Chinese.

What's inside

Introduction
Packaging Contents
System Block Diagram
Motherboard Specifications
Installation Guide
BIOS Settings
RAID Configuration
Driver Installation
Appendices

Specifications

CPU Socket	Socket 939
Chipset	VIA K8T890 + VT8237R
Maximum Memory	4 GB
Expansion Slots	3 PCI, 1 PCI‑E ×16, 2 PCI‑E ×1
USB Ports	8 USB 2.0 (4 on back panel)
IDE Ports	2 IDE ports (supports 4 devices)
IDE Transfer Mode	UDMA‑33, ATA‑66/100/133
SATA Ports	2 SATA (150 MB/s, RAID 0/1/JBOD)
Form Factor	ATX, 30.5 × 24.5 cm

Frequently asked questions

How do I enter the VIA RAID BIOS configuration?

Press the key during boot to open the VIA RAID BIOS setup program.

What should I do if the BIOS is inserted incorrectly?

Re‑check the BIOS orientation and reinstall it correctly.

How can I clear the CMOS?

Clear the CMOS or press the Insert key while powering on.

Download PDF (10.8 MB)
