The document provides the technical specifications and features of the GA-K8VT800(Pro) motherboard, including supported processor types, memory specifications, interface types, etc.
The manual explains how to safely install the GA‑K8VT800(Pro) motherboard, covering preparation steps such as disconnecting power, handling components with anti‑static precautions, and attaching the CPU heatsink. Detailed warnings remind users not to run the processor without a properly installed heatsink and to avoid using unsupported AGP cards.
It also lists the board’s hardware layout, including the 30.5 cm × 23.0 cm form factor, VIA K8T800 chipset, three DDR DIMM slots supporting up to 3 GB of memory, AGP 4X/8X (1.5 V) slots, five PCI slots, and integrated IDE and RAID controllers. BIOS configuration options and technical reference data are provided in later chapters. This manual is written in Chinese.
| Form factor | 30.5 cm × 23.0 cm |
|---|---|
| Maximum CPU speed | 1.6 GHz |
| Supported memory types | DDR400 / DDR333 / DDR266, unbuffered ECC DIMMs |
| Maximum memory capacity | 3 GB (using 128 MB‑1 GB modules) |
| Chipset | VIA K8T800 AGP/PCI Controller (PAC) |
| AGP support | AGP 4X/8X (1.5 V) only |
| PCI slots | 5 slots, 33 MHz, PCI 2.3 compliant |
| IDE controller | Integrated IDE, UDMA 33/ATA66/ATA100/ATA133 |
| RAID controller | IT8212F |
| I/O controller | ITE8705 |
The board supports up to 3 GB of RAM using 128 MB, 256 MB, 512 MB, or 1 GB unbuffered DIMM modules.
