This manual provides detailed information on the nForce 520 chipset. The manual covers all details of the nForce 520 chipset, including installation, configuration, and usage.
The manual covers safety precautions, unpacking, and detailed installation steps for the AMD Socket AM2 motherboard equipped with the nVidia nForce 520 chipset. It includes BIOS configuration, hardware monitoring, and troubleshooting guidance for common issues such as memory errors and RAID setup.
Key sections describe the motherboard specifications, supported CPUs, memory types, expansion slots, USB and SATA interfaces, audio codec, and power‑management features like Cool'n'Quiet and Smart Fan. The document also provides a troubleshooting table with error codes and recommended solutions. This manual is written in Japanese.
| Socket type | Socket AM2 (940 pin) |
|---|---|
| Chipset | nVidia nForce 520 |
| Memory type | DDR2 SDRAM DIMM |
| Supported memory speeds | DDR2‑533/667/800 dual‑channel |
| Maximum memory capacity | 16 GB |
| USB ports | 10 USB 2.0 ports (4 rear) |
| Ethernet | 1 Gigabit Ethernet port |
| SATA ports | 4 SATA II ports, 300 MB/s, RAID 0/1 |
| Audio codec | Realtek ALC8xx, 6‑channel |
Work in an anti‑static environment, avoid unnecessary connections to the motherboard, and protect the board from static discharge to prevent damage.
Reinstall the memory modules or replace faulty memory modules.
