EPoX EP-4BDAL Pentium 4 AGP Mainboard User Manual

This manual introduces the functions and usage methods of the Asus A Pentium 4 Processor based AGP (4X) mainboard (100MHz) mainboard.

Brand: Pentium
Category: Motherboard
Document type: User Manual
Language: English
Pages: 90
File format: PDF
File size: 9.7 MB
Published: 05 April, 2012
Updated: 01 October, 2023
MD5 checksum: AD26B6314B58AD2B89042C8035516494
PDF: EPoX EP-4BDAL Pentium 4 AGP Mainboard User Manual PDF

About this manual

The EP-4BDAL is a Pentium 4‑processor‑based AGP (4X) mainboard built around the Intel® 845 chipset, which includes the Memory Controller Hub (MCH), I/O Controller Hub (ICH2) and Firmware Hub (FWH). The board supports 266 MHz DDR SDRAM, a 400 MHz processor bus, and provides AGP 4X, Ultra ATA/66/100, USB, LAN and other interfaces for a balanced system architecture.

The manual covers component checklists, detailed layout diagrams, CPU and memory installation, jumper settings, BIOS configuration, driver installation, and safety handling procedures. It also includes appendices for media player guides, BIOS updates, EEPROM removal, and optional software utilities, plus contact information for EPoX technical support worldwide.

What's inside

Introduction
Components Checklist
System Overview
Chipset Components
Installation Procedure
BIOS Setup
Driver Installation
Appendix A – Media Player Guide
Appendix B – BIOS Update
Technical Support

Specifications

Chipset	Intel 845
AGP Interface	4X, 1.5 V only
DDR SDRAM Support	Up to 2 GB, 200/266 MHz
Processor Bus Speed	400 MHz
IDE Controller	2‑Channel Ultra ATA/33/66/100 Bus Master

Frequently asked questions

What chipset does the EP-4BDAL mainboard use?

It uses the Intel 845 chipset.

How much DDR SDRAM can the board support?

The board supports up to 2 GB of DDR SDRAM at 200/266 MHz.

Where is the serial number located on the EP-4BDAL board?

The serial number is printed near the PCI slots at the edge of the board.
