K 6264 K is an electronic component produced by Texas Instruments. It is a 38MHz IF filter that can be switched between M/N mode and D/K mode. The M/N mode has a Nyquist slope and a sound shelf at 33.50MHz, while the D/K mode has a Nyquist slope and a broad sound shelf for sound carriers at 31.50MHz and 32.50MHz. The component is suitable for CENELEC EN 55020.
The K 6264 K is a surface acoustic wave (SAW) IF filter designed for intercarrier and multistandard applications around 38 MHz. It offers switchable M/N and D/K modes, constant group delay, and compliance with CENELEC EN 55020.
The sheet lists electrical characteristics, frequency‑response plots, time‑domain responses, and mechanical data such as package type (DIP10K), dimensions, and temperature limits. Maximum ratings, ordering codes, and contact information are also included.
| Operating temperature range | -25 °C to +65 °C |
|---|---|
| Storage temperature range | -40 °C to +85 °C |
| DC voltage rating | 12 V |
| AC voltage rating | 10 V |
| Package type | DIP10K (standard plastic) |
| Weight | 1.8 g |
| Reference frequency | 38.00 MHz |
The filter operates from –25 °C up to +65 °C.
The component is rated for a DC voltage of 12 V.
It is supplied in a standard plastic DIP10K package.
