This manual provides detailed instructions on how to operate and service the PA30 Print Engine
The Intermec PA30 Print Engine User Manual provides detailed instructions for unpacking, installing, and setting up the PA30 print engine. It includes safety information, hardware overview, and step‑by‑step procedures for configuring print and media settings.
The manual also covers web‑based management, troubleshooting, and specifications such as dimensions, power requirements, and print capabilities. It serves technicians and end users who need to operate or service the PA30 in standalone or applicator configurations.
| Operating mode | Peel‑off (self‑strip) |
|---|---|
| Print modes | Direct thermal, thermal transfer |
| Resolution | 8 dots/mm (203/300 dpi) |
| Print speed | 100 to 300 mm/sec (4 to 12 in/sec) |
| Print width | Direct thermal max 112 mm, thermal transfer max 110 mm |
| Dimensions (W × L × H) | 24.45 cm × 51.12 cm × 30.16 cm |
| Weight (excluding media) | 6.11 kg (13.48 lb) |
| Operating temperature | +5 °C to +40 °C (+41 °F to +104 °F) |
| Power consumption | Minimum 20 W, continuous 125 W (average), peak 400 W |
The PA30 measures 24.45 cm × 51.12 cm × 30.16 cm (W × L × H).
It needs a minimum of 20 W, about 125 W during continuous printing, and can peak at 400 W.
The manual describes a Web Browser Interface that allows configuration of settings through a browser.
The PA30 supports Direct thermal and Thermal transfer print modes.
