5962-0721301QXC, 5962-0721302QXC, 5962-0721303QYC 500MHz rail-to-rail amplifiers
The 5962‑0721301QXC (and its sibling parts 5962‑0721302QXC and 5962‑0721303QYC) are rail‑to‑rail amplifiers offering a 500 MHz -3 dB bandwidth, 600 V/µs slew rate and inputs that extend 0.15 V below the negative rail. They operate from 3 V to 5.5 V, draw only 13.5 mA per channel, and include a fast‑acting disable circuit (25 ns) with a 200 ns enable time.
The devices are supplied in 10‑lead (K10.A) or 14‑lead (K14.A) ceramic metal‑seal flat‑pack packages. Pinouts, absolute maximum ratings, thermal information and detailed electrical specifications are provided in the datasheet, along with package dimension drawings.
| -3 dB Bandwidth | 500 MHz |
|---|---|
| Slew Rate | 600 V/µs |
| Supply Voltage Range | 3 V to 5.5 V |
| Input Range | 0.15 V below Vs‑ |
| Enable Time | 200 ns |
| Disable Time | 25 ns |
| Supply Current per Channel | 13.5 mA |
| Operating Temperature Range | -55 °C to +125 °C |
| Package Type | 10‑lead flat‑pack (K10.A) |
It has a 500 MHz -3 dB bandwidth.
The enable time is 200 ns, and the disable time is 25 ns.
It operates from 3 V up to 5.5 V.
It is supplied in a 10‑lead ceramic metal‑seal flat‑pack (K10.A).
