The HM-6617/883 2K x 8 CMOS PROM is a low power synchronous design, using Intersil's advanced self-aligned silicon gate CMOS process technology, offering ultra-low standby current.
The HM-6617/883 is a 16,384‑bit fuse‑link CMOS PROM offered in a 2 K‑word by 8‑bit/word format with three‑state outputs. It features a single 5 V supply, CMOS/TTL compatible inputs, and high‑output drive capability, making it suitable for low‑power and battery‑operated applications.
The document details absolute maximum ratings, DC and AC electrical performance specifications, pin descriptions, functional diagrams, and recommended handling procedures. Key parameters such as supply voltage range, operating temperature range, access times, and output voltage levels are listed for designers.
| Supply Voltage Range | +4.5 V to +5.5 V |
|---|---|
| Operating Temperature Range | -55 °C to +125 °C |
| High Level Output Voltage (VOH1) | VCC = 4.5 V |
The device operates from +4.5 V to +5.5 V.
It is rated for operation from –55 °C up to +125 °C.
