5962-0625601QXC, 5962-0625602QXC 1.4GHz Current Feedback Amplifiers with Enable
The 5962‑0625601QXC (and its counterpart 5962‑0625602QXC) are high‑bandwidth current‑feedback amplifiers designed for video, RGB, cable‑driver and test‑equipment applications. They operate from a single or dual supply of 5 V to 12 V and feature a fast enable/disable pin that reduces quiescent current.
Key specifications include a gain‑of‑1 bandwidth of 1.4 GHz, gain‑of‑2 bandwidth of 800 MHz, 6000 V/µs slew rate, 12 mA typical supply current, 1.5 pF input capacitance and low input noise. The device is supplied in a 10‑lead flat‑pack package with detailed pin assignments for IN+, IN‑, OUT, V+, V‑ and CE.
| Gain‑of‑1 Bandwidth | 1.4 GHz |
|---|---|
| Gain‑of‑2 Bandwidth | 800 MHz |
| Slew Rate | 6000 V/µs |
| Supply Current (typical) | 12 mA |
| Supply Voltage Range | 5 V to 12 V |
| Enable/Disable Current Reduction | ~13 µA |
| Input Capacitance | 1.5 pF |
| Input Current Noise | 50 pA/√Hz |
| Enable Time | 170 ns |
| Disable Time | 1.25 µs |
The gain‑of‑1 bandwidth is 1.4 GHz.
It operates from 5 V up to 12 V.
Typical supply current is 12 mA.
Yes, it includes a fast enable/disable pin that reduces current to about 13 µA when disabled.
