HA-2520/883 is a high-performance operational amplifier from Intersil that offers unsurpassed specifications for slew rate, bandwidth and settling time. It is designed for closed loop gains of 3 or greater without external compensation and provides low offset current and high input impedance. The 100V/µs (min) slew rate and fast settling time make it ideal for pulse amplification and data acquisition designs.
The HA-2520/883 is a monolithic operational amplifier offering a high slew rate, wide gain bandwidth, and low offset current, making it suitable for pulse amplification, data‑acquisition, RF, and video circuits. It is supplied in an 8‑pin metal can package and is tested for AC performance over the full temperature range.
The document lists absolute maximum ratings, operating conditions, thermal data, and detailed electrical performance tables, including slew rate, bandwidth, input impedance, and quiescent current. Package dimensions, lead layout, and MIL‑STD‑883 test requirements are also provided for designers.
| Quiescent Supply Current | 6 mA (max) |
|---|---|
| Package Type | 8‑Pin Metal Can |
The device is supplied in an 8‑pin metal can package; the pinout is shown in the datasheet.
