The HI-200/883 is a monolithic device comprising two independently selectable SPST switchers which feature fast switching speeds (240ns typical) combined with low power dissipation (15mW typical @ +25°C). Each switch provides low “ON” resistance operation for input signal voltages up to the supply rails and for signal currents up to 25mA continuous. Rugged DI construction eliminates latch-up and substrate SCR failure modes. All devices provide break-before-make switching and are TTL and CMOS compatible for maximum application versatility. HI-200/883 is an ideal component for use in high frequency analog switching. Typical applications include signal path switching, sample and hold circuits, digital filters, and op amp gain switching networks.
The HI-200/883 is a monolithic dual SPST CMOS analog switch offering fast 240 ns typical switching speed and low power dissipation (15 mW typical @ +25 °C). Each switch handles up to 25 mA continuous current and operates over a wide analog voltage range, making it suitable for high‑frequency analog switching, sample‑and‑hold circuits, digital filters, and op‑amp gain switching networks.
The datasheet includes detailed electrical characteristics such as on‑resistance, turn‑on/off times, absolute maximum ratings, and recommended operating conditions. It also provides pinout diagrams, package dimensions for the 10‑pin metal‑can (TO‑99) package, and test circuit examples for verification.
| Continuous Current | 25 mA |
|---|
The device can handle up to 25 mA continuous current.
