The HA-2510/883 is a high performance operational amplifier which sets the standards for maximum slew rate and wide bandwidth operation in moderately powered, internally compensated, monolithic devices. In addition to excellent dynamic characteristics, this dielectrically isolated amplifier also offers low offset current and high input impedance. The ±50V/µs minimum slew rate and fast settling time of the HA-2510/883 are ideally suited for high speed D/A, A/D, and pulse amplification designs. The HA-2510/883’s superior bandwidth and 750kHz minimum full power bandwidth are extremely useful in RF and video applications. To insure compliance with slew rate and transient response specifications, all devices are 100% tested for AC performance characteristics over full temperature limits. To improve signal conditioning accuracy, the HA-2510/883 provides a maximum offset current of 25nA and a minimum input impedance of 50MΩ, both at 25oC, as well as offset voltage adjust capability.
The HA-2510/883 is a high‑performance, internally compensated operational amplifier offering a minimum 50 V/µs slew rate, 750 kHz full‑power bandwidth, and high input impedance. It is designed for high‑speed data‑conversion, pulse amplification, and RF/video applications.
The document lists absolute maximum ratings, operating conditions, thermal data, and detailed electrical performance tables for both DC and AC characteristics. Package information for metal‑can and CERDIP versions, as well as mechanical dimensions, are also included.
| Full‑Power Bandwidth (minimum) | 750 kHz |
|---|---|
| Input Impedance (minimum) | 50 MΩ |
| Quiescent Supply Current (maximum) | 6 mA |
| Operating Temperature Range | -55 °C to 125 °C |
The device has a minimum input impedance of 50 MΩ.
The maximum quiescent supply current is 6 mA.
