The ISL95710 is a digitally controlled potentiometer from Intersil. It is packaged in a 10 LD MSOP and has an output voltage of ±2.7V to ±5V. It offers 128 taps and has an up/down interface.
The Intersil ISL95710 is a digitally controlled potentiometer (XDCP) that provides a resistor array of 127 elements and 128 wiper tap points. The wiper position is set via Up/Down, Increment and Chip Select inputs and can be stored in non‑volatile memory for recall on power‑up.
The device operates from a supply voltage of +2.7 V to +5.5 V, offers ultra‑low standby current (1 pA) and a maximum active current of 3 mA. It is offered in a 10‑lead Mini‑Small‑Outline Plastic (MSOP) package and meets RoHS and ISO‑9000 quality standards.
| Supply voltage | +2.7 V to +5.5 V |
|---|---|
| Wiper tap points | 128 |
| Standby current | 1 pA |
| Active current (max) | 3 mA |
| Endurance | 200,000 data changes per bit |
| Data retention | 50 years |
| Temperature coefficient (Rtota) | +50 ppm/°C |
| End‑to‑end resistance tolerance | +20 % |
It operates from +2.7 V to +5.5 V.
The device provides 128 wiper tap points.
The wiper position is stored in non‑volatile memory and recalled on power‑up.
