The AD9979 is a highly integrated CCD signal processor for high speed digital video camera applications.
The AD9979 is a highly integrated CCD signal processor designed for high‑speed digital video camera applications. It features a 14‑bit, 65 MHz ADC, a 10‑bit variable gain amplifier (6 dB‑42 dB), a precision timing core with 240 ps resolution, on‑chip 3 V horizontal and RG drivers, and internal LDO regulator circuitry.
The device is offered in a compact 7 mm × 7 mm, 48‑lead LFCSP package and operates over a temperature range of –25 °C to +85 °C. Typical applications include professional HDTV camcorders, high‑end digital and broadcast cameras, and industrial high‑speed cameras.
| Core supply voltage | 1.8 V analog and digital |
|---|---|
| Variable gain amplifier (VGA) range | 6 dB to 42 dB, 10‑bit |
| ADC resolution and speed | 14‑bit, 65 MHz |
| Precision timing resolution | 240 ps at 65 MHz |
| Horizontal and RG driver voltage | 3 V |
| Package | 7 mm × 7 mm, 48‑lead LFCSP |
| Operating temperature range | ‑25 °C to +85 °C |
| Internal regulator | LDO regulator circuitry |
The AD9979 includes a 14‑bit analog‑to‑digital converter operating at 65 MHz.
It is available in a 7 mm × 7 mm, 48‑lead LFCSP package.
The device operates from –25 °C up to +85 °C.
