ADG431/ADG432/ADG433 is a low-power quad MOS switch with low on-resistance, high switching speed and low power consumption.
The ADG431, ADG432 and ADG433 are precision quad SPST analog switches fabricated on an enhanced CMOS process. They offer a wide analog signal range (up to ±15 V), low on‑resistance (<24 mΩ), ultralow leakage (<0.25 nA), and fast switching times (ton < 165 ns, torr < 130 ns). The devices are TTL/CMOS compatible and can operate from a single supply as low as 5 V.
Typical applications include audio/video switching, automatic test equipment, precision data acquisition, battery‑powered instruments and sample‑and‑hold circuits. The parts feature break‑before‑make switching, low charge injection, and trench isolation for latch‑up protection.
| Supply Voltage (Dual) | ±15 V (max) |
|---|---|
| On‑Resistance (Ron) typical | 17 mΩ typ |
| Leakage Current (OFF) source | 0.05 nA typ |
| Leakage Current (OFF) drain | 0.05 nA typ |
| Switching time (ton) | ≤165 ns typ |
| Switching time (torr) | ≤130 ns typ |
| Power Dissipation | 1.9 µW max (single‑supply) |
| Operating Temperature Range (B‑Version) | -40 °C to +85 °C |
The devices are rated for a maximum dual supply of ±15 V (44 V total).
Typical on‑resistance is 17 mΩ.
