The ADG711/ADG712/ADG713 are monolithic CMOS devices containing four independently selectable switches. These switches are characterized by low on resistance (2.5 ohm typical), low on resistance flatness, -3 dB bandwidth > 200 MHz, rail-to-rail operation, 16-lead TSSOP and SOIC packages, fast switching times (tON 16 ns, tOFF 10 ns), and typical power consumption (< 0.01 mW).
The ADG711, ADG712, and ADG713 are monolithic CMOS devices that provide four independently selectable SPST switches. They operate from a single 1.8 V to 5.5 V supply, making them suitable for battery‑powered instruments, USB 1.1 signal routing, audio/video switching, and mechanical reed‑relay replacement.
Key features include low on‑resistance (2.5 Ω typ), high bandwidth (>200 MHz), fast switching (ton 16 ns, toff 10 ns), and availability in 16‑lead TSSOP and SOIC packages. Detailed specifications, pin configurations, truth tables, and typical performance graphs are provided.
| Supply Voltage Range | 1.8 V to 5.5 V |
|---|---|
| Bandwidth | >200 MHz (-3 dB) |
| Turn‑On Time (ton) | 16 ns typ |
| Turn‑Off Time (toff) | 10 ns typ |
| Typical Power Consumption | <0.01 W |
| Source OFF Leakage Current | 0.01 nA typ |
| Package Options | 16‑Lead TSSOP and 16‑Lead SOIC |
They operate from a single 1.8 V to 5.5 V supply.
Turn‑on time is about 16 ns and turn‑off time about 10 ns.
They are offered in 16‑lead TSSOP and 16‑lead SOIC packages.
