The ADXL327 is a small, low power, 3-axis accelerometer with features such as small size, low power consumption, and single-supply operation. It is suitable for cost-sensitive, low power motion and tilt sensing applications.
The ADXL327 accelerometer from Analog Devices provides three‑axis acceleration sensing in a compact 4 mm × 4 mm × 1.45 mm LFCSP package. It operates from a single supply of 1.8 V to 3.6 V and draws only 350 µA typical current, making it suitable for battery‑powered devices.
The device offers selectable bandwidth from 0.5 Hz to 1600 Hz (X/Y) or 550 Hz (Z) using external capacitors, and includes built‑in self‑test, low‑noise performance, and robust ESD protection. Detailed pinout, electrical specifications, and layout recommendations are provided for designers.
| Measurement Range | +2 g (min) / +2.5 g (typ) |
|---|---|
| Sensitivity (X/Y/Z) at 3 V | 378 mV/g (X), 420 mV/g (Y), 462 mV/g (Z) |
| Operating Voltage Range | 1.8 V – 3.6 V |
| Supply Current (3 V) | 350 µA typical |
| Bandwidth (X/Y) | 0.5 Hz – 1600 Hz (no external filter) |
| Bandwidth (Z) | 0.5 Hz – 550 Hz (no external filter) |
| Operating Temperature Range | -40 °C – +85 °C |
| Noise Density | 250 pg/√Hz rms |
The ADXL327 measures acceleration from a minimum of +2 g up to a typical +2.5 g.
It operates from a single supply voltage between 1.8 V and 3.6 V.
The typical supply current is 350 µA when powered at 3 V.
